Features and Specifications

Manufactured from virgin pipe grade raw materials (PE80, PE100).
Excellent corrosion and chemical resistance. Inert to most acidic and alkaline solutions.
High flow characteristics.
Light in Weight.
Easy to handle & transport.
Excellent flexibility combined with strength.
Good abrasion resistance.
Smooth inner walls minimises frictional losses.
Safe for potable water supply.
Manufactured as per IS-4984, ISO-4427, DIN8074, ASTM D 3035 and BS-6437 standards in PE-63, PE-80 and PE-100 grades.
Manufactured from 20 to 2500 mm sizes at various pressure rating from 2.5 to 16 kg/cm² (35.5 to 227.5 psi).
Upto 6" in straight lengths and coils. Higher sizes in standard and other straight lengths only.

Applications

Technical Specifications

PE Pipe as per ISO:4427:96
Material Grade PE 63

OD		PN 3.2		PN 4		PN 6		PN 6.3		PN 8		PN10		PN12.5		PN16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
16.0	16.3	-	-	-	-	-	-	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8	2.8	3.3
25.0	25.3	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8	2.3	2.8	2.8	3.3	3.5	4.1
32.0	32.3	-	-	-	-	2.3	2.8	2.3	2.8	2.4	2.9	2.9	3.4	3.6	4.2	4.4	5.1
40.0	40.4	-	-	2.3	2.8	2.3	2.8	2.4	2.9	3.0	3.5	3.7	4.3	4.5	5.2	5.5	6.4
50.0	50.5	-	-	2.3	2.8	2.9	3.4	3.0	3.5	3.7	4.3	4.6	5.3	5.6	6.5	6.9	8.0
63.0	63.6	2.3	2.8	2.5	3.0	3.6	4.2	3.8	4.4	4.7	5.5	5.8	6.7	7.1	8.2	8.6	9.9
75.0	75.7	2.3	2.8	2.9	3.4	4.3	5.0	4.5	5.2	5.6	6.5	6.8	7.9	8.4	9.7	10.3	11.9
90.0	90.9	2.8	3.3	3.5	4.1	5.1	6.0	5.4	6.3	6.7	7.8	8.2	9.5	10.1	11.7	12.3	14.2
110.0	111.0	3.4	4.0	4.2	4.9	6.3	7.3	6.6	7.6	8.1	9.4	10.0	11.5	12.3	14.2	15.1	17.4
125.0	126.2	3.9	4.5	4.8	5.6	7.1	8.2	7.4	8.6	9.2	10.6	11.4	13.2	14	16.1	17.1	20.5
140.0	141.3	4.3	5.0	5.4	6.3	8.0	9.2	8.3	9.6	10.3	11.9	12.7	14.7	15.7	18.4	19.2	23.0
160.0	161.5	4.9	5.7	6.2	7.2	9.1	10.5	9.5	11.0	11.8	13.6	14.6	16.8	17.9	21.2	21.9	26.2
180.0	181.7	5.5	6.4	6.9	8.0	10.2	11.8	10.7	12.4	13.3	15.3	16.4	19.6	20.1	24.1	24.6	29.5
200.0	201.8	6.2	7.2	7.7	8.9	11.4	13.2	11.9	13.7	14.7	17.0	18.2	21.8	22.4	26.8	27.4	32.8
225.0	227.1	6.9	8.0	8.6	9.9	12.8	14.8	13.4	15.5	16.6	19.9	20.5	24.5	25.2	30.2	30.8	36.9
250.0	252.3	7.7	8.9	9.6	11.1	14.2	16.4	14.8	17.1	18.4	22.0	22.7	27.2	27.9	33.4	34.2	41.0
280.0	282.6	8.6	10.0	10.7	12.4	15.9	18.3	16.6	19.9	20.6	24.7	25.4	30.4	31.3	37.5	38.3	45.9
315.0	317.9	9.7	11.2	12.1	14.0	17.9	21.4	18.7	22.4	23.2	27.8	28.6	34.3	35.2	42.2	43.1	51.7
355.0	358.2	10.9	12.6	13.6	15.7	20.1	24.2	21.1	25.3	26.1	31.3	32.2	38.6	39.7	47.6	48.5	58.1
400.0	403.6	12.3	14.2	15.3	17.6	22.7	27.3	23.7	28.4	29.4	35.2	36.3	43.5	44.7	53.6	54.7	64.6
450	454.1	13.8	15.9	17.2	20.6	25.5	30.6	26.7	32.0	33.1	39.7	40.9	49.0	50.3	60.2	61.5	71.4
500	504.5	15.3	17.6	19.1	22.9	28.3	33.9	29.7	35.6	36.8	44.1	45.4	54.4	55.8	65.7	-	-
560	565.0	17.2	20.6	21.4	25.6	31.7	38.0	33.2	39.8	41.2	49.4	50.8	60.7	-	-	-	-
630	635.7	19.3	23.1	24.1	28.9	35.7	42.8	37.4	44.8	46.3	55.5	57.2	67.1	-	-	-	-
710	716.4	21.8	26.1	27.2	32.6	40.2	48.2	42.1	50.5	52.2	62.1	-	-	-	-	-	-
800	807.2	24.5	29.3	30.6	36.7	45.3	54.3	47.4	56.8	58.8	68.7	-	-	-	-	-	-
900	908.1	27.6	33.1	34.4	41.2	51.0	60.9	53.3	63.2	-	-	-	-	-	-	-	-
1000	1009	30.6	36.7	38.2	45.8	56.6	66.5	59.3	69.2	-	-	-	-	-	-	-	-
1200	1210	36.7	44.0	45.9	55.0	-	-	-	-	-	-	-	-	-	-	-	-
1400	1410	42.9	51.3	53.5	63.4	-	-	-	-	-	-	-	-	-	-	-	-
1600	1610	49.0	58.7	61.2	71.1	-	-	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 80

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
16.0	16.3	-	-	-	-	-	-	-	-	2.3	2.8
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3
32.0	32.3	-	-	-	-	-	-	3.0	3.5	3.6	4.2
40.0	40.4	-	-	-	-	-	-	3.7	4.3	4.5	5.2
50.0	50.5	-	-	-	-	-	-	4.6	5.3	5.6	6.5
63.0	63.6	-	-	-	-	4.7	5.5	5.8	6.7	7.1	8.2
75.0	75.7	-	-	4.5	5.2	5.6	6.5	6.8	7.9	8.4	9.7
90.0	90.9	4.3	5.0	5.4	6.3	6.7	7.8	8.2	9.5	10.1	11.7
110.0	111.0	5.3	6.1	6.6	7.6	8.1	9.4	10.0	11.5	12.3	14.2
125.0	126.2	6.0	6.9	7.4	8.6	9.2	10.6	11.4	13.2	14.0	16.1
140.0	141.3	6.7	7.9	8.3	9.6	10.3	11.9	12.7	14.7	15.7	18.1
160.0	161.5	7.7	8.9	9.5	11.0	11.8	13.6	14.6	16.8	17.9	21.4
180.0	181.7	8.6	9.9	10.7	12.4	13.3	15.3	16.4	19.6	20.1	24.1
200.0	201.8	9.6	11.1	11.9	13.7	14.7	17.0	18.2	21.8	22.4	26.8
225.0	227.1	10.8	12.5	13.4	15.5	16.6	19.8	20.5	24.5	25.2	30.2
250.0	252.3	11.9	13.7	14.8	17.1	18.4	22.0	22.7	27.2	27.9	33.4
280.0	282.6	13.4	15.5	16.6	19.9	20.6	24.7	25.4	30.4	31.3	37.5
315.0	317.9	15.0	17.3	18.7	22.4	23.2	27.8	28.6	34.3	35.2	42.2
355.0	358.2	16.9	20.2	21.1	25.3	26.1	31.3	32.2	38.6	39.7	47.6
400.0	403.6	19.9	22.9	23.7	28.4	29.4	35.2	36.3	43.5	44.7	53.6
450	454.1	21.5	25.7	26.7	32.0	33.1	39.7	40.9	49.0	50.3	60.2
500	504.5	23.9	28.6	29.7	35.6	36.8	44.1	45.4	53.4	55.8	65.7
560	565.0	26.7	32.0	33.2	39.8	41.2	49.4	50.8	60.7	-	-
630	635.7	30.0	35.9	37.4	44.8	46.3	55.5	57.2	67.1	-	-
710	716.4	33.9	40.6	42.1	50.5	52.2	62.1	-	-	-	-
800	807.2	38.1	45.7	47.4	56.8	58.8	68.7	-	-	-	-
900	908.1	42.9	51.4	53.3	63.2	-	-	-	-	-	-
1000	1009	47.7	57.2	59.3	69.2	-	-	-	-	-	-
1200	1210	57.2	67.1	-	-	-	-	-	-	-	-
1400	1410	-	-	-	-	-	-	-	-	-	-
1600	1610	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 100

OD		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
32.0	32.3	-	-	-	-	3.0	3.5
40.0	40.4	-	-	-	-	3.7	4.3
50.0	50.5	-	-	-	-	4.6	5.3
63.0	63.6	-	-	4.7	5.5	5.8	6.7
75.0	75.7	4.5	5.2	5.6	6.5	6.8	7.9
90.0	90.9	5.4	6.3	6.7	7.8	8.2	9.5
110.0	111.0	6.6	7.6	8.1	9.4	10.0	11.5
125.0	126.2	7.4	8.6	9.2	10.6	11.4	13.2
140.0	141.3	8.3	9.6	10.3	11.9	12.7	14.7
160.0	161.5	9.5	11.0	11.8	13.6	14.6	16.8
180.0	181.7	10.7	12.4	13.9	15.3	16.4	19.6
200.0	201.8	11.9	13.7	14.7	17.0	18.2	21.8
225.0	227.1	13.4	15.5	16.6	19.9	20.5	24.5
250.0	252.3	14.8	17.1	18.4	22.0	22.7	27.2
280.0	282.6	16.6	19.9	20.6	24.7	25.4	30.4
315.0	317.9	18.7	22.4	23.2	27.8	28.6	34.3
355.0	358.2	21.1	25.3	26.1	31.3	32.2	38.6
400.0	403.6	23.7	28.4	29.4	35.2	36.3	43.5
450.0	454.1	26.7	32.0	33.1	39.7	40.9	49.0
500.0	504.5	29.7	35.6	36.8	44.1	45.4	54.4
560.0	565.0	33.2	39.8	41.2	49.4	50.8	60.7
630.0	635.7	37.4	44.8	46.2	55.4	57.2	67.1
710.0	716.4	42.1	50.5	52.2	62.1	-	-
800.0	807.2	47.4	56.8	58.8	68.7	-	-
900.0	908.1	53.3	63.2	-	-	-	-
1000.0	1009.0	59.3	69.2	-	-	-	-

Pressure Rating in : Kg/cm²

PE Pipe as per IS:4984:95 (With Amendment)

Material Grade PE 63

All dimension are in mm

OD		PN 2.5		PN 4		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8	2.8	3.3	3.4	4.0
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3	3.4	4.0	4.2	4.9
32.0	32.3	-	-	-	-	2.3	2.8	3.0	3.5	3.6	4.2	4.4	5.1	5.4	6.2
40.0	40.4	-	-	2.0	2.4	2.8	3.3	3.7	4.3	4.5	5.2	5.5	6.3	6.7	7.6
50.0	50.5	-	-	2.4	2.9	3.5	4.1	4.6	5.3	5.6	6.4	6.8	7.7	8.4	9.5
63.0	63.6	2.0	2.4	3.0	3.5	4.4	5.1	5.8	6.6	7.0	7.9	8.6	9.7	10.5	11.8
75.0	75.7	2.3	2.8	3.6	4.2	5.3	6.1	6.9	7.8	8.4	9.5	10.2	11.5	12.5	14.0
90.0	90.9	2.8	3.3	4.3	5.0	6.3	7.2	8.2	9.3	10.0	11.2	12.2	13.7	15.0	16.7
110.0	111.0	3.4	4.0	5.3	6.1	7.7	8.7	10.0	11.2	12.3	13.8	14.9	16.6	18.4	20.5
125.0	126.2	3.8	4.4	6.0	6.8	8.8	9.9	11.4	12.8	13.9	15.5	16.9	18.8	20.9	23.2
140.0	141.3	4.3	5.0	6.7	7.6	9.8	11.0	12.8	14.3	15.6	17.4	19.0	21.1	23.4	26.0
160.0	161.5	4.9	5.6	7.7	8.7	11.2	12.6	14.6	16.3	17.8	19.8	21.7	24.1	26.7	29.6
180.0	181.7	5.5	6.3	8.6	9.7	12.6	14.1	16.4	18.3	20.0	22.2	24.4	27.1	30.0	33.2
200.0	201.8	6.1	7.0	9.6	10.8	14.0	15.6	18.2	20.3	22.3	24.8	27.1	30.1	33.4	37.0
225.0	227.1	6.9	7.8	10.8	12.1	15.7	17.5	20.5	22.8	25.0	27.7	30.5	33.8	37.5	41.5
250.0	252.3	7.6	8.6	12.0	13.4	17.5	19.5	22.8	25.3	27.8	30.8	33.8	37.4	41.7	46.1
280.0	282.6	8.5	9.6	13.4	15.0	19.6	21.8	25.5	28.3	31.2	34.6	37.9	41.9	46.7	51.6
315.0	317.9	9.6	10.8	15.0	16.7	22.0	24.4	28.7	31.8	35.0	38.7	42.6	47.1	52.5	58.0
355.0	358.2	10.8	12.1	17.0	18.9	24.8	27.5	32.3	35.8	39.5	43.7	48.0	53.0	59.2	65.4
400.0	403.6	12.2	14.3	19.1	22.2	28.0	32.4	36.4	42.8	44.5	51.4	54.1	62.5	-	-
450.0	454.1	13.7	16.0	21.5	25.0	31.4	36.4	41.1	47.4	50.0	57.7	-	-	-	-
500.0	504.5	15.2	17.7	23.9	27.7	34.9	40.4	45.5	52.6	55.6	64.2	-	-	-	-
560.0	565.0	17.0	19.8	26.7	31.0	39.1	45.2	51.0	58.9	-	-	-	-	-	-
630.0	635.7	19.1	22.2	30.0	34.7	44.0	50.8	57.3	66.1	-	-	-	-	-	-
710.0	716.4	21.6	25.1	33.9	39.2	49.6	57.3	-	-	-	-	-	-	-	-
800.0	807.2	24.3	28.2	38.1	44.1	55.9	64.5	-	-	-	-	-	-	-	-
900.0	908.1	27.3	31.6	42.9	49.6	-	-	-	-	-	-	-	-	-	-
1000.0	1009.0	30.4	35.2	47.7	55.1	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 80

All dimension are in mm

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3
25.0	25.3	-	-	-	-	2.3	2.8	2.8	3.3	3.5	4.1
32.0	32.3	-	-	2.4	2.9	3.0	3.5	3.6	4.2	4.5	5.2
40.0	40.4	2.3	2.8	3.0	3.5	3.7	4.3	4.5	5.2	5.6	6.4
50.0	50.5	2.9	3.4	3.8	4.4	4.6	5.3	5.6	6.4	6.9	7.8
63.0	63.6	3.6	4.2	4.7	5.4	5.8	6.6	7.0	7.9	8.7	9.8
75.0	75.7	4.3	5.0	5.6	6.4	6.9	7.8	8.4	9.5	10.4	11.7
90.0	90.9	5.1	5.9	6.7	7.6	8.2	9.3	10.0	11.2	12.5	14.0
110.0	111.0	6.3	7.2	8.2	9.3	10.0	11.2	12.3	13.8	15.2	17.0
125.0	126.2	7.1	8.1	9.3	10.5	11.4	12.8	13.9	15.5	17.3	19.3
140.0	141.3	8.0	9.0	10.4	11.7	12.8	14.3	15.6	17.4	19.4	21.6
160.0	161.5	9.1	10.3	11.9	13.3	14.6	16.3	17.8	19.8	22.1	24.6
180.0	181.7	10.2	11.5	13.4	15.0	16.4	18.3	20.0	22.2	24.9	27.6
200.0	201.8	11.4	12.8	14.9	16.6	18.2	20.3	22.3	24.8	27.6	30.6
225.0	227.1	12.8	14.3	16.7	18.6	20.5	22.8	25.0	27.7	31.1	34.5
250.0	252.3	14.2	15.9	18.6	20.7	22.8	25.3	27.8	30.8	34.5	38.2
280.0	282.6	15.9	17.7	20.8	23.1	25.5	28.3	31.2	34.6	38.7	42.8
315.0	317.9	17.9	19.9	23.4	26.0	28.7	31.8	35.0	38.7	43.5	48.1
355.0	358.2	20.1	22.4	26.3	29.2	32.3	35.8	39.5	43.7	49.0	54.1
400.0	403.6	22.7	26.4	29.7	34.4	36.4	42.1	44.5	51.4	55.2	63.7
450.0	454.1	25.5	29.6	33.4	38.7	41.0	47.7	50.0	57.7	-	-
500.0	504.5	28.4	32.9	37.1	42.9	45.5	52.6	55.6	64.2	-	-
560.0	565.0	31.7	36.7	41.5	48.0	51.0	58.9	-	-	-	-
630.0	635.7	35.7	41.3	46.7	54.0	57.3	66.1	-	-	-	-
710.0	716.4	40.2	46.5	52.6	60.7	-	-	-	-	-	-
800.0	807.2	45.3	52.3	-	-	-	-	-	-	-	-
900.0	908.1	51.0	58.9	-	-	-	-	-	-	-	-
1000.0	1009.0	56.7	65.5	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 100

All dimension are in mm

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.9	3.4
32.0	32.3	-	-	-	-	2.4	2.9	2.9	3.4	3.7	4.3
40.0	40.4	-	-	2.4	2.9	3.0	3.5	3.7	4.3	4.6	5.3
50.0	50.5	2.3	2.8	3.0	3.5	3.7	4.3	4.6	5.3	5.7	6.5
63.0	63.6	2.9	3.4	3.8	4.4	4.7	5.4	5.7	6.5	7.1	8.1
75.0	75.7	3.5	4.1	4.5	5.2	5.6	6.4	6.8	7.7	8.5	9.6
90.0	90.9	4.1	4.8	5.4	6.2	6.7	7.6	8.2	9.3	10.2	11.5
110.0	111.0	5.0	5.7	6.6	7.5	8.1	9.2	10.0	11.2	12.4	13.9
125.0	126.2	5.7	6.5	7.5	8.5	9.2	10.4	11.3	12.7	14.1	15.8
140.0	141.3	6.4	7.3	8.4	9.5	10.3	11.6	12.7	14.2	15.8	17.6
160.0	161.5	7.3	8.3	9.6	10.8	11.8	13.2	14.5	16.2	18.1	20.2
180.0	181.7	8.2	9.3	10.8	12.1	13.3	14.9	16.3	18.2	20.3	22.6
200.0	201.8	9.1	10.3	12.0	13.4	14.8	16.5	18.1	20.2	22.6	25.1
225.0	227.1	10.3	11.6	13.5	15.1	16.6	18.5	20.4	22.7	25.4	28.2
250.0	252.3	11.4	12.8	15.0	16.7	18.4	20.5	22.6	25.1	28.2	31.3
280.0	282.6	12.8	14.3	16.8	18.7	20.6	22.9	25.3	28.1	31.6	35.0
315.0	317.9	14.4	16.1	18.9	21.0	23.2	25.8	28.5	31.6	35.5	39.3
355.0	358.2	16.2	18.1	21.2	23.6	26.2	29.1	32.1	35.6	40.0	44.2
400.0	403.6	18.2	21.2	23.9	27.7	29.5	34.2	36.2	41.9	45.1	52.1
450.0	454.1	20.5	23.8	26.9	31.2	33.1	38.3	40.7	47.7	50.8	58.7
500.0	504.5	22.8	26.5	29.9	34.6	36.8	42.6	45.2	52.2	56.4	65.1
560.0	565.0	25.5	29.6	33.5	38.8	41.2	47.6	50.6	58.4	-	-
630.0	635.7	28.7	33.3	37.7	43.6	46.4	53.6	56.9	65.7	-	-
710.0	716.4	32.3	37.4	42.4	49.0	52.3	60.4	-	-	-	-
800.0	807.2	36.4	42.1	47.8	55.2	58.9	68.0	-	-	-	-
900.0	908.1	41.0	47.4	53.8	62.1	-	-	-	-	-	-
1000.0	1009.0	45.5	52.6	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

PE Pipe as per DIN:8074-99

OD		Pipe Series 25		Pipe Series 20		Pipe Series 16		Pipe Series 12.5		Pipe Series 10.5		Pipe Series 10		Pipe Series 8.3		Pipe Series 8.0		Pipe Series 6.3		Pipe Series 5.0		Pipe Series 4.0		Pipe Series 3.2		Pipe Series 2.5		Pipe Series 2.0
Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max
10	10.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.0	2.4
12	12.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.0	2.4	2.4	2.9
16	16.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.2	2.7	2.7	3.2	3.3	3.9
20	20.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.3	2.8	2.8	3.3	3.4	4.0	4.1	4.8
25	25.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.3	2.8	2.8	3.3	3.5	4.1	4.2	4.9	5.1	5.9
32	32.3	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.4	2.9	2.9	3.4	3.6	4.2	4.4	5.1	5.4	6.2	6.5	7.4
40	40.4	-	-	-	-	-	-	1.8	2.2	1.9	2.3	1.9	2.3	2.3	2.8	2.4	2.9	3.0	3.5	3.7	4.3	4.5	5.2	5.5	6.3	6.7	7.6	8.1	9.2
50	50.5	-	-	-	-	1.8	2.2	2.0	2.4	2.3	2.8	2.4	2.9	2.9	3.4	3.0	3.0	3.7	4.3	4.6	5.3	5.6	6.4	6.9	7.8	8.3	9.4	10.1	11.4
63	63.6	-	-	1.8	2.2	2.0	2.4	2.5	3.0	2.9	3.4	3.0	3.5	3.6	4.1	3.8	4.4	4.7	5.4	5.8	6.6	7.1	8.1	8.6	9.7	10.5	11.8	12.7	14.2
75	75.7	1.8	2.2	1.9	2.3	2.3	2.8	2.9	3.4	3.5	4.1	3.6	4.2	4.3	5.0	4.5	5.2	5.6	6.4	6.8	7.7	8.4	9.5	10.3	11.6	12.5	14.0	15.1	16.9
90	90.9	1.8	2.2	2.2	2.7	2.8	3.3	3.5	4.1	4.1	4.8	4.3	5.0	5.1	5.9	5.4	6.2	6.7	7.6	8.2	9.3	10.1	11.4	12.3	13.8	15.0	16.7	18.1	20.2
110	111.0	2.2	2.7	2.7	3.2	3.4	4.0	4.2	4.9	5.0	5.7	5.3	6.1	6.3	7.2	6.6	7.5	8.1	9.2	10.0	11.2	12.3	13.8	15.1	16.9	18.3	20.4	22.1	24.6
125	126.2	2.5	3.0	3.1	3.7	3.9	4.5	4.8	5.5	5.7	6.5	6.0	6.8	7.1	8.1	7.4	8.4	9.2	10.4	11.4	12.8	14.0	15.6	17.1	19.1	20.8	23.1	25.1	27.9
140	141.3	2.8	3.3	3.5	4.1	4.3	5.0	5.4	6.2	6.4	7.3	6.7	7.6	8.0	9.0	8.3	9.4	10.3	11.6	12.7	14.2	15.7	17.5	19.2	21.4	23.3	25.9	28.1	31.2
160	161.5	3.2	3.8	4.0	4.6	4.9	5.6	6.2	7.1	7.3	8.3	7.7	8.7	9.1	10.3	9.5	10.7	11.8	13.2	14.6	16.3	17.9	19.9	21.9	24.3	26.6	29.5	32.1	35.6
180	181.7	3.6	4.2	4.4	5.1	5.5	6.3	6.9	7.8	8.2	9.3	8.6	9.7	10.2	11.5	10.7	12.0	13.3	14.9	16.4	18.3	20.1	22.4	24.6	27.3	29.9	33.1	36.1	40.0
200	201.8	3.9	4.5	4.9	5.6	6.2	7.1	7.7	8.7	9.1	10.3	9.6	10.8	11.4	12.8	11.9	13.3	14.7	16.4	18.2	20.3	22.4	24.9	27.4	30.4	33.2	36.8	40.1	44.4
225	227.1	4.4	5.1	5.5	6.3	6.9	7.8	8.6	9.7	10.3	11.6	10.8	12.1	12.8	14.3	13.4	15.0	16.6	18.5	20.5	22.8	25.2	28.0	30.8	34.1	37.4	41.4	45.1	49.9
250	252.3	4.9	5.6	6.2	7.1	7.7	8.7	9.6	10.8	11.4	12.8	11.9	13.3	14.2	15.9	14.8	16.5	18.4	20.5	22.7	25.2	27.9	30.9	34.2	37.9	41.6	46.0	50.1	55.4
280	282.6	5.5	6.3	6.9	7.8	8.6	9.7	10.7	12.0	12.8	14.3	13.4	15.0	15.9	17.7	16.6	18.5	20.6	22.9	25.4	28.2	31.3	34.7	38.3	42.4	46.5	51.4	56.2	62.1
315	317.9	6.2	7.1	7.7	8.7	9.7	10.9	12.1	13.6	14.4	16.1	15.0	16.7	17.9	19.9	18.7	20.8	23.2	25.8	28.6	31.7	35.2	39.1	43.1	47.7	52.3	57.8	63.2	69.8
355	358.2	7.0	7.9	8.7	9.8	10.9	12.2	13.6	15.2	16.2	18.1	16.9	18.8	20.1	22.4	21.1	23.5	26.1	29.0	32.2	35.7	39.7	43.9	48.5	53.6	59.0	65.1	-	-
400	403.6	7.9	8.9	9.8	11.0	12.3	13.8	15.3	17.1	18.2	20.3	19.1	21.3	22.7	25.2	23.7	26.3	29.4	32.6	36.3	40.2	44.7	49.4	54.7	60.4	66.5	73.4	-	-
450	453.8	8.8	9.9	11.0	12.3	13.8	15.4	17.2	19.2	20.5	22.8	21.5	23.9	25.5	28.3	26.7	29.6	33.1	36.7	40.9	45.2	50.3	55.6	61.5	67.9	-	-	-	-
500	504.0	9.8	11.0	12.3	13.8	15.3	17.1	19.1	21.3	22.8	25.3	23.9	26.5	28.4	31.5	29.7	32.9	36.8	40.7	45.4	50.2	55.8	61.6	68.3	75.4	-	-	-	-
560	564.3	11.0	12.3	13.7	15.3	17.2	19.2	21.4	23.8	25.5	28.3	26.7	29.6	31.7	35.1	33.2	36.8	41.2	45.6	50.8	56.1	62.5	69.0	-	-	-	-	-	-
630	634.6	12.3	13.7	15.4	17.2	19.3	21.5	24.1	26.8	28.7	31.8	30.0	33.2	35.7	39.5	37.4	41.4	46.3	51.2	57.2	63.2	-	-	-	-	-	-	-	-
710	714.9	13.9	15.5	17.4	19.4	21.8	24.2	27.2	30.2	32.3	35.8	33.9	37.5	40.2	44.5	42.1	46.6	52.2	57.7	64.5	71.2	-	-	-	-	-	-	-	-
800	805.0	15.7	17.5	19.6	21.8	24.5	27.2	30.6	33.9	36.4	40.3	38.1	42.2	45.3	50.1	47.4	52.4	58.8	64.9	-	-	-	-	-	-	-	-	-	-
900	905.0	17.6	19.6	22.0	24.4	27.6	30.6	34.4	38.1	41.0	45.3	42.9	47.4	51.0	56.3	53.3	58.9	66.1	73.0	-	-	-	-	-	-	-	-	-	-
1000	1005.0	19.6	21.8	24.5	27.2	30.6	33.9	38.2	42.3	45.5	50.3	47.7	52.7	56.7	62.6	59.3	65.5	-	-	-	-	-	-	-	-	-	-	-	-
1200	1208.5	23.5	26.1	29.4	32.6	36.7	40.6	45.9	50.7	54.6	60.3	57.2	63.2	68.0	75.0	-	-	-	-	-	-	-	-	-	-	-	-	-	-
1400	1408.5	27.4	30.4	34.4	38.1	42.9	47.4	53.5	59.1	63.7	70.3	66.7	73.6	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
1600	1608.5	31.3	34.7	39.2	43.4	49.0	48.0	61.2	67.6	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

PE Pipe as per ASTM D 3035 (PE 3408)

Nom. Dia.		Outside Dia.	Minimum Wall Thickness in mm
inch	mm	mm	DR32.5	DR26	DR21	DR17	DR15.5	DR13.5	DR11	DR9.3	DR9	DR7
½"	21	21.34	1.57	1.57	1.57	1.57	1.57	1.57	1.93	2.29	2.36	3.05
¾"	27	26.70	1.57	1.57	1.57	1.57	1.73	1.98	2.41	2.87	2.97	3.81
1"	33	33.40	1.57	1.57	1.60	1.96	2.13	2.46	3.05	3.58	3.71	4.78
1¼"	42	42.20	1.57	1.63	2.01	2.49	2.72	3.12	3.84	4.52	4.67	6.02
1½"	48	48.30	1.57	1.85	2.29	2.84	3.12	3.58	4.39	5.18	5.36	6.88
2"	60	60.30	1.85	2.31	2.87	3.56	3.89	4.47	5.49	6.48	6.71	8.61
3"	89	88.90	2.74	3.43	4.24	5.23	5.74	6.58	8.08	9.55	9.88	12.70
4"	114	114.30	3.51	4.39	5.44	6.73	7.37	8.46	10.39	12.29	12.70	16.33
5"	141	141.30	4.34	5.44	6.73	8.31	9.12	10.46	12.85	15.19	15.70	20.19
6"	168	168.28	5.18	6.48	8.00	9.91	10.85	12.47	15.29	18.08	18.69	24.03
8"	219	219.08	6.73	8.43	10.44	12.88	14.12	16.23	19.91	23.55	24.33	31.29
10"	273	273.05	8.41	10.49	13.00	16.05	17.63	20.22	24.82	29.36	30.33	39.01
12"	324	323.85	9.96	12.45	15.42	19.05	20.90	23.98	29.44	34.82	35.99	46.25
14"	357	355.60	10.95	13.67	16.94	20.93	22.94	26.34	32.33	38.23	39.52	50.80
16"	408	406.40	12.50	15.62	19.35	23.90	26.21	30.10	36.96	43.69	45.16	58.06
18"	459	457.20	14.07	17.58	21.77	26.90	29.49	33.86	41.55	49.15	50.80	65.30
20"	510	508.00	15.62	19.53	24.18	29.87	32.77	37.62	46.18	54.64	56.44	72.57
22"	561	558.80	16.94	21.49	26.62	32.87	36.04	41.40	50.80	60.10	62.08	79.83
24"	612	609.60	18.75	23.44	29.03	35.86	39.32	45.16	55.42	65.56	67.74	87.10

Dimensions

Designation of Material


About Us History Founder Board of Directors Corporate Philosophy Awards & Accolades Worldwide Locations Gratitude Sustainability at JAINS Associates Login India - Offices & Depot Overseas office	Resources Events Calculator Videos Krishiteerth Weather Station Downloads Environment Policy Privacy Policy Terms & Conditions	Micro Irrigation Systems Drip Lines / Drip Tapes Drip Tubes / Drippers Drip Kits Jets & Foggers Mini Micro Sprinklers Overhead Sprinklers Rainguns Landscape Sprinklers Filters / Valves Fertigation Systems	Monitoring & Control Jain Logic Turnkey Solutions Resource To Root 24/7 Drinking Water Solutions	PVC & PE Pipes & Fittings PVC Pipes & Fittings HDPE Pipes & Fittings Silicoat PE OFC Ducts Corrugated Pipes & Fittings PE Gas Pipes & Fittings PE Sewerage Pipes & Fittings PE Perforated Pipes Hot & Cold Water Plumbing Cold Water Plumbing Underground Drainage	Solar Products Solar Pumping Systems Solar Power Generation Solar Water Heaters Solar Lighting & Appliances Photovoltaic Module Plastic Sheet PVC Free Foam Sheet PVC Integral Sheet /Rigid Sheet PVC Pro Sheet / Glo Sheet
